External Contracting Handbrake Linkage, Cam, Pin, Fixing, Nut and Spring SET
Joe's Motor Pool produced, External Contracting Handbrake Linkage, Cam, Pin, Bolt, Nut and Spring Set for Ford GPW and Willys MB.
For models-
Willys MB Slat: All Willys MB: SOP - September 1944 (Up Until MB 37337) Ford GPW: All
Joe's Motor Pool produced, External Contracting Handbrake Linkage, Cam, Pin, Bolt, Nut and Spring Set for Ford GPW and Willys MB.
Made as original these Handbrake Band Linkage Kits were used on Willys MB Slat and MB from SOP - Sept 1944 (MB 37337) and all Ford GPW's.
In this set you will get you will get all Pins, Links, Bolts, Nuts and springs to fit your handbrake system, see list below:
x2 PIN , Clevis, S, 5/16 x 1 (WO-311003, FM-73904S7) - P67, AA
x1 PIN , Clevis, 1/2 x 1 3/16 (to operating cam) (WO-A1004, FM-73928S7) - P67, E
x1 PIN , Clevis, S, 1/4 X 3/4 (cable to crank) (WO-392488, FM-357553S18) - P67, U
x2 CAM , Operating (WO-A1003, GPW2632) - P67, F
x2 LINK , Cable Crank to Operating Arm (WO-A1228, GPW2659) - P67, H
x1 LINK , Operating Arm to Transfer Case (WO-A1005, GPW2630) - P67, J
x1 CRANK , Cable, Assy – WO-A1226, GPW2656 (P67, S)
x1 BOLT , Adjusting, Band (Also known as ROD) (WO-A1016, FM01T2642) - P67, G
x1 BOLT , Adjusting Band Anchor Clip (hex-hd, S, 5/16-18 NC-2 x 1 5/8) (WO-A1020, GPW2616) - P67, N
x1 BOLT , Shoulder, hex-hd, S, 7/16-20 NF-2 x 1 1/2 (WO-A1227, FM355752S) - P67, T
x1 SCREW , fil-hd, S, cd-pltd, 1/4-20 NC-2 X 2 3/4 (WO-A1019, FM-355352S7) - P67, Z
x1 NUT , Adjusting, Band (Special) (WO-A1018, FM-01T2805) P67, V
x1 NUT , Jam, Hex, Light, s-fin, S, cd or zn-pltd, 7/16-20 NF-2 (124929) - P67, W
x2 NUT , Hex, Light, s-fin, S, cd or zn-pltd, ¼-20 NC-2 (120375) - P67, X
x4 PIN , Cotter, Split, S, 3/32 x 1 (103374) - P67, K, L
x1 PIN , Cotter, Split, S, 1/16 x 5/8 (107761)
x2 SPRING , Release, Band (WO-A1017, FM-01T2634) - P67, R
x1 SPRING , Band Anchor Clip Bolt (WO-A1021, FM-01T2640) - P67, P
x1 SPRING , Cable Handle Ratchet (WO-635681, GPW2793)
1 Set required per vehicle.
More Information
More Information
Vehicles
Ford GP, Ford GPA, Ford GPW, Willys MB, Willys MB SLAT GRILL, Hotchkiss M201
Willys Number
See Description
Ford Number
See Description
Catalogue Reference
P67, E, F, G, H, J, N, S, T, U, V, W, X, Z, AA
Catalogue Part Name
PIN, LINK, CAM, SPRING, CRANK, BOLT, NUT AND SCREW
